Wi-Fi access points
GWN7604
Wi-Fi 6 Access Point with Integrated PoE Switch. The GWN7604 is a compact and versatile Wi-Fi 6 Access Point with 4 Gigabit Ethernet ports, including one uplink port that can receive PoE/PoE+ to power the access point…
- Up to 256Client Devices
- 573.5Mbps (2x2:2 MU-MIMO)2.4G Throughput
- 2.4Gbps (3x3:2 MU-MIMO)5G Throughput
Product details
The GWN7604 is a compact and versatile Wi-Fi 6 Access Point with 4 Gigabit Ethernet ports, including one uplink port that can receive PoE/PoE+ to power the access point and two ports with PSE that can provide PoE and a network connection to other devices.
Key features
3Gbps aggregate wireless throughput, 4x Gigabit ports
Up to 100 meters coverage range
Self power adaptation upon auto detection of PoE/PoE+ and PSE
Anti-hacking secure boot and critical data/control lockdown via digital signatures, unique security certificate/random default password per device
Supports up to 256 concurrent Wi-Fi client devices
Advanced QoS to ensure real-time performance of low-latency applications
DoC - GWN7604
Specifications
| Specification | Value |
|---|---|
| Specifications | |
| Client Devices | Up to 256 |
| 2.4G Throughput | 573.5Mbps (2x2:2 MU-MIMO) |
| 5G Throughput | 2.4Gbps (3x3:2 MU-MIMO) |
| 6G Throughput | N/A |
| Range | Up to 100 Meters |
| Network Interfaces | 1 x 10/100/1000M uplink Ethernet port with POE/POE+ 2 x 10/100/1000M Ethernet port with PSE 1 x 10/100/1000M Ethernet port |
| PoE/PoE+ | PoE 802.3af/ 802.3at PSE max output: Total 12W power budget for LAN2/LAN3 Maximum Power Consumption: 7.5W (Excluding PoE Output) |
| Wi-Fi Standards | IEEE 802.11a/b/g/n/ac/ax |
| SSIDs | 32 SSIDs total, 16 per radio (2.4GHz and 5 GHz) |
| Antennas | 2 x dual-band internal antennas,1x 5G internal antenna |
| Wi-Fi and Security Systems | WEP, WPA/WPA2-PSK, WPA/WPA2 Enterprise (TKIP/AES); WPA3, anti-hacking secure boot and critical data/ control lockdown via digital signatures, unique security certificate and random default password per device |
| Dimensions | 135mm(L) x 115mm(H) x 30mm(W) |
| Mounting | Indoor Wall mount |
