Wi-Fi access points
GWN7605
802.11ac Wave-2 2x2:2. The GWN7605 is an affordable 802.11ac Wave-2 Wi-Fi access point ideal for small to medium wireless network deployments with medium user density. It offers dual-band 2x2:2 MU-MIMO with…
- 100+Client Devices
- 300Mbps (2x2:2 MIMO)2.4G Throughput
- 867Mbps (2x2:2 MU-MIMO)5G Throughput
Product details
The GWN7605 is an affordable 802.11ac Wave-2 Wi-Fi access point ideal for small to medium wireless network deployments with medium user density. It offers dual-band 2x2:2 MU-MIMO with beam-forming technology and a sophisticated antenna design for maximum network throughput and expanded Wi-Fi coverage range.
Key features
1.27Gbps aggregate wireless throughput and 2xGigabit wireline ports
Dual-band 2x2:2 MU-MIMO with beamforming technology
Self power adaptation upon auto detection of PoE/PoE+
Supports 100+ concurrent Wi-Fi client devices
Up to 165-meter coverage range
Advanced QoS to ensure real-time performance of low-latency applications
Anti-hacking secure boot and critical data/control lockdown via digital signatures, unique security certificate/random default password per device
Embedded controller can manage up to 50 local GWN series APs; GDMS Networking offers unlimited AP management; GWN Manager offers premise-based software controller
DoC - GWN7605
Specifications
| Specification | Value |
|---|---|
| Specifications | |
| Client Devices | 100+ |
| 2.4G Throughput | 300Mbps (2x2:2 MIMO) |
| 5G Throughput | 867Mbps (2x2:2 MU-MIMO) |
| 6G Throughput | N/A |
| Range | Up to 165 Meters |
| Network Interfaces | 2 x autosensing 10/100/1000 Base-T Ethernet Ports |
| PoE/PoE+ | Supports PoE 802.3af/ 802.3at; Max Consumption: 10.16W |
| Wi-Fi Standards | IEEE 802.11a/b/g/n/ac (Wave-2) |
| SSIDs | 16 SSIDs total, 8 per radio (2.4Ghz and 5Ghz) |
| Antennas | 2 dual band internal antennas |
| Wi-Fi and Security Systems | WEP, WPA/WPA2-PSK, WPA/ WPA2 Enterprise (TKIP/AES), WPA3, anti-hacking secure boot and critical data/ control lockdown via digital signatures |
| Dimensions | 180.4x180.4x40.8mm |
| Mounting | Indoor wall mount or ceiling mount |
