GWN7660
The GWN7660 is an enterprise-grade 802.11ax Wi-Fi 6 access point that allows businesses to build next-generation Wi-Fi networks for high-density environments.
- 250+Client Devices
- 573.5Mbps (2x2:2 MIMO)2.4G Throughput
- 1201Mbps (2x2:2 MU-MIMO)5G Throughput
Product details
The GWN7660 is an enterprise-grade 802.11ax Wi-Fi 6 access point that allows businesses to build next-generation Wi-Fi networks for high-density environments.
GWN 2x2:2 Wi-Fi 6 Indoor Access Point
Key features
1.77Gbps aggregate wireless throughput and 2x Gigabit Ethernet ports
Dual-band 2x2:2 MUMIMO with DL/UL OFDMA technology
Up to 175-meter coverage range
Supports 500+ concurrent Wi-Fi client devices
Advanced QoS to ensure real-time performance of low-latency applications
Anti-hacking secure boot and critical data/control lockdown via digital signatures, unique security certificate/random default password per device
Self-power adaptation upon auto detection of PoE or PoE+
Embedded controller can manage up to 50 local GWN series APs; GDMS Networking offers unlimited AP management; GWN Manager offers premise based software controller
DoC - GWN7660
Specifications
| Specification | Value |
|---|---|
| Specifications | |
| Client Devices | 250+ |
| 2.4G Throughput | 573.5Mbps (2x2:2 MIMO) |
| 5G Throughput | 1201Mbps (2x2:2 MU-MIMO) |
| 6G Throughput | N/A |
| Range | Up to 175 Meters |
| Network Interfaces | 2x autosensing 10/100/1000 Base-T Ethernet Ports |
| PoE/PoE+ | Supports PoE 802.3af/ 802.3at; Max Consumption: 9W |
| Wi-Fi Standards | IEEE 802.11 a/b/g/n/ac/ax |
| SSIDs | 32 SSIDs total, 16 per radio (2.4Ghz and 5Ghz) |
| Antennas | 2 dual band internal antennas |
| Wi-Fi and Security Systems | WEP, WPA/WPA2-PSK, WPA/ WPA2 Enterprise (TKIP/AES); WPA3, anti-hacking secure boot and critical data/control lockdown via digital signatures, unique security certificate and random default password per device |
| Dimensions | 180.4x180.4x40.8mm |
| Mounting | Indoor wall mount or ceiling mount, kits included |
