Wi-Fi access points
GWN7660ELR
The GWN7660ELR is an enterprise-grade long-range Wi-Fi 6 access point that allows businesses to build next-generation Wi-Fi networks for high-density environments.
- Up to 256Client Devices
- 300 MetersRange
- 573.5Mbps (2x2:2 MIMO)2.4G Throughput
Product details
The GWN7660ELR is an enterprise-grade long-range Wi-Fi 6 access point that allows businesses to build next-generation Wi-Fi networks for high-density environments.
GWN Enterprise-Grade 2x2:2 Wi-Fi 6 Weatherproof Long-Range Access Point
Key features
3 Gbps aggregate wireless throughput, 1 Gbps RJ45, and 2.5 Gbps SFP wireline ports
Dual-band 2x2:2 MIMO with OFDMA technology
Self-power adaptation upon auto-detection of PoE or PoE+
Support 256 concurrent Wi-Fi client devices
Up to 300-meter coverage range
Advanced QoS to ensure real-time performance of low-latency applications
Anti-hacking secure boot and critical data/control lockdown via digital signatures, unique security certificate/random default password per device
Flexibility of 5 internal antennas
Embedded controller manages up to 50 local GWN APs; GDMS Networking offers unlimited AP management, & GWN Manager offers on-premise software AP management
DoC - GWN7660ELR
Specifications
| Specification | Value |
|---|---|
| Specifications | |
| Client Devices | Up to 256 |
| Range | 300 Meters |
| Network Interfaces | 1x 1G RJ45 Port and 1x 2.5G SFP Port |
| PoE/PoE+ | Supports PoE 802.3af / 802.3at; Maximum Power Consumption: 13W |
| 2.4G Throughput | 573.5Mbps (2x2:2 MIMO) |
| 5G Throughput | 2.4Gbps (2x2:2 MIMO) |
| Wi-Fi Standards | IEEE 802.11 b/g/n/ac/ax |
| SSIDs | 32 SSIDs total, 16 per radio |
| Antennas | 5 individual internal antennas |
| Wi-Fi and Security Systems | WPA/WPA2-PSK, WPA/WPA2 Enterprise (TKIP/AES); WPA3, anti-hacking secure boot and critical data/control lockdown via digital signatures, unique security certificate and random default password per device |
| Dimensions | 270mm x 230mm x 57mm |
| Mounting | Wall mount or pole mount, kits included (The mounting kits can be adjusted and rotated by 60°) |
More from this range
View the range →
Interested in this product?
Request a quote: our team will confirm availability, compatibility and a deployment plan.
