Wi-Fi access points
GWN7660EM
Wi-Fi 6 Extender and Access Point. The GWN7660EM IS an AX3000 Wi-Fi 6 access point with a pluggable socket design, providing an easy-to-install solution for offices and homes. It can also be used as a Wi-Fi extender to…
- 128Client Devices
- 573.5Mbps (2x2:2 MU-MIMO)2.4G Throughput
- 2.4Gbps (3x3:2 MU-MIMO)5G Throughput
Product details
The GWN7660EM IS an AX3000 Wi-Fi 6 access point with a pluggable socket design, providing an easy-to-install solution for offices and homes. It can also be used as a Wi-Fi extender to quickly build a wireless mesh solution thats expand network coverage.
Key features
3Gbps aggregate wireless throughput and 1 Gigabit wireline port
Dual-band 2.4G 2x2:2 and 5G 3x3:2 MU- MIMO with OFMDA and XTRA Range technology
Up to 120-meter coverage range
Supports 128 concurrent Wi-Fi client devices
Advanced QoS to ensure real-time performance of low-latency applications
Anti-hacking secure boot and critical data/control lockdown via digital signatures, unique security certificate/random default password per device
Supports Mesh networking with the GWN7062E/ET series, future Grandstream Routers, and other GWN series access points to provide easy network expansion
Embedded controller can manage up to 10 local GWN series APs; GDMS Networking offers unlimited AP management; GWN Manager offers premise-based software controller
Specifications
| Specification | Value |
|---|---|
| Specifications | |
| Client Devices | 128 |
| 2.4G Throughput | 573.5Mbps (2x2:2 MU-MIMO) |
| 5G Throughput | 2.4Gbps (3x3:2 MU-MIMO) |
| 6G Throughput | N/A |
| Range | Up to 120 Meters |
| Network Interfaces | 1x autosensing 10/100/1000 Base-T Ethernet Port |
| PoE/PoE+ | N/A |
| Wi-Fi Standards | IEEE 802.11a/b/g/n/ac/ax |
| SSIDs | 16 SSIDs total, 8 per radio (2.4Ghz and 5Ghz) |
| Antennas | 1 single frequency antenna and 2 dual frequency antennas |
| Wi-Fi and Security Systems | WPA2-PSK (personal) WPA2-802.1x (enterprise) WPA3-SAE (personal) WPA3-802.1x (enterprise) WPA/WPA2, WPA2/WPA3 Anti-hacking secure boot and critical data/control lockdown via digital signatures, unique security certificate and random default password per device, Open system OSEN, MAC filtering Client isolation OS filtering, Inbound/outbound traffic rules Rogue AP detection and containment ARP attack defense ND attack defense |
| Dimensions | 110mmx110mmx56.7mm |
| Mounting | Indoor wall-plug mount |
