Wi-Fi access points
GWN7662
The GWN7662 is an enterprise-grade 802.11ax Wi-Fi 6 access point that allows businesses to build next generation Wi-Fi networks for high-density environments.
- Up to 256Client Devices
- 573.5Mbps (2x2:2 MIMO)2.4G Throughput
- 4804Mbps (4x4:4 MU-MIMO)5G Throughput
Product details
The GWN7662 is an enterprise-grade 802.11ax Wi-Fi 6 access point that allows businesses to build next generation Wi-Fi networks for high-density environments.
GWN 2x2:2 & 4x4:4 Wi-Fi 6 Indoor Access Point
Key features
5.38 Gbps wireless throughput and 3.5 Gigabit wireline ports
5GHz 4×4:4 MU-MIMO with DL/UL OFDMA technology
Up to 175-meter coverage range
Supports 256 concurrent Wi-Fi client devices
Advanced QoS to ensure real-time performance of low-latency applications
Anti-hacking secure boot and critical data/control lockdown via digital signatures, unique security certificate/random default password per device
Self power adaptation upon auto detection of PoE or PoE+
Embedded controller can manage up to 50 local GWN series APs; GDMS Networking offers unlimited AP management; GWN Manager offers premise based software controller
DoC - GWN7662
Specifications
| Specification | Value |
|---|---|
| Specifications | |
| Client Devices | Up to 256 |
| 2.4G Throughput | 573.5Mbps (2x2:2 MIMO) |
| 5G Throughput | 4804Mbps (4x4:4 MU-MIMO) |
| 6G Throughput | N/A |
| Range | Up to 175 Meters |
| Network Interfaces | 1x autosensing 10/100/1000 Base-T Ethernet Port, 1x autosensing 10/100/1000/2500 Base-T Ethernet Port |
| PoE/PoE+ | Supports 802.3az; PoE 802.3af/ 802.3at; Maximum Power Consumption: 16W |
| Wi-Fi Standards | IEEE 802.11 a/b/g/n/ac(Wave-2)/ax |
| SSIDs | 32 SSIDs total, 16 per radio (2.4GHz & 5GHz) |
| Antennas | 6 single frequency internal antennas |
| Wi-Fi and Security Systems | WEP, WPA/WPA2-PSK, WPA/WPA2 Enterprise (TKIP/AES); WPA3, anti-hacking secure boot and critical data/ control lockdown via digital signatures |
| Dimensions | 205.3mmx205.3mmx45.9mm |
| Mounting | Indoor wall mount or ceiling mount |
