Wi-Fi access points
GWN7664
The GWN7664 is a powerful, enterprise-grade 802.11ax Wi-Fi 6 access point, ideal for medium-to-large sized businesses, multiple floor buildings, residential settings and commercial locations.
- Up to 750Client Devices
- 1147Mbps (4x4:4 MIMO)2.4G Throughput
- 2400Mbps (4x4:4 MU-MIMO)5G Throughput
Product details
The GWN7664 is a powerful, enterprise-grade 802.11ax Wi-Fi 6 access point, ideal for medium-to-large sized businesses, multiple floor buildings, residential settings and commercial locations.
GWN 4x4:4 Wi-Fi 6 Indoor Access Point
Key features
3.55Gbps aggregate wireless throughput, 3.5Gbps aggregate wired throughput
Dual-band 4x4:4 MU-MIMO with DL/UL OFDMA technology
Up to 175-meter coverage range
Supports 750+ concurrent Wi-Fi client devices
Includes 1x 1G Port and 1x 2.5G Port
Mesh networks and enterprise roaming
Advanced QoS to ensure real-time performance of low-latency applications
Anti-hacking secure boot and critical data/control lockdown via digital signatures, unique security certificate/random default password per device
Self-power adaptation upon auto detection of PoE or PoE+
Embedded controller manages up to 50 local GWN APs; GDMS Networking offers unlimited AP management, & GWN Manager offers on-premise software AP management
DoC - GWN7664
Specifications
| Specification | Value |
|---|---|
| Specifications | |
| Client Devices | Up to 750 |
| 2.4G Throughput | 1147Mbps (4x4:4 MIMO) |
| 5G Throughput | 2400Mbps (4x4:4 MU-MIMO) |
| 6G Throughput | N/A |
| Range | Up to 175 Meters |
| Network Interfaces | 1x 1G Port and 1 x 2.5G Port |
| PoE/PoE+ | Supports PoE 802.3af/802.3at; Max Consumption: 17w |
| Wi-Fi Standards | IEEE 802.11 a/b/g/n/ac/ax |
| SSIDs | 32 SSIDs total, 16 per radio (2.4 Ghz and 5Ghz) |
| Antennas | 8 individual internal antennas, 4 per band |
| Wi-Fi and Security Systems | WEP, WPA/WPA2-PSK, WPA/ WPA2 Enterprise (TKIP/AES); WPA3, anti-hacking secure boot and critical data/control lockdown via digital signatures, unique security certificate and random default password per device |
| Dimensions | 205.3x205.3x405.9mm |
| Mounting | Indoor wall mount or ceiling mount, kits included |
