Wi-Fi access points
GWN7665
GWN 802.11ax Tri-Band Wi-Fi 6E Access Point. The GWN7665 is a powerful, enterprise-grade Wi-Fi 6E access point for business-grade wireless network deployments with medium-to-high user density.
- Up to 384Client Devices
- 573.5Mbps (2x2:2 MU-MIMO)2.4G Throughput
- 2.4Gbps (2x2:2 MU-MIMO)5G Throughput
Product details
The GWN7665 is a powerful, enterprise-grade Wi-Fi 6E access point for business-grade wireless network deployments with medium-to-high user density.
Key features
5.4Gbps aggregate wireless throughput, 3.5 Gigabit wireline ports
Tri-Band 2x2:2 MU-MIMO with DL/UL OFDMA technology
Up to 175-meter coverage range
Support 384 concurrent Wi-Fi client devices
Advanced QoS to ensure real-time performance of low-latency applications
Anti-hacking secure boot and critical data/control lockdown via digital signatures, unique security certificate/random default password per device
Self-power adaptation upon auto-detection of PoE or PoE+
Embedded controller manages up to 50 local GWN APs; GDMS Networking offers unlimited AP management, & GWN Manager offers on-premise software AP management
DoC - GWN7665
Specifications
| Specification | Value |
|---|---|
| Specifications | |
| Client Devices | Up to 384 |
| 2.4G Throughput | 573.5Mbps (2x2:2 MU-MIMO) |
| 5G Throughput | 2.4Gbps (2x2:2 MU-MIMO) |
| 6G Throughput | 2.4Gbps (2x2:2 MU-MIMO) |
| Range | Up to 175 Meters |
| Network Interfaces | 1x autosensing 10/100/1000 Base-T Ethernet Port, 1x autosensing 10/100/2500 Base-T Ethernet Port |
| PoE/PoE+ | Supports 802.3az, PoE 802.3af/ 802.3at; Maximum Power Consumption: 22.5W |
| Wi-Fi Standards | Tri-Band IEEE 802.11 a/b/g/n/ac/ax |
| SSIDs | 48 total, 16 per radio (2.4GHz, 5GHz and 6GHz) |
| Antennas | 7 individual internal antennas |
| Wi-Fi and Security Systems | WEP, WPA/WPA2-PSK, WPA/WPA2 Enterprise (TKIP/AES); WPA3, anti-hacking secure boot and critical data/ control lockdown via digital signatures, unique security certificate and random default password per device |
| Dimensions | 205.3mm x 205.3mm x 45.9mm |
| Mounting | Indoor wall mount or ceiling mount |
