HT813
Hybrid ATA with FXS and FXO Ports. The HT813 is an analog telephone adapter that features 1 analog telephone FXS port and 1 PSTN line FXO port.
Product details
The HT813 is an analog telephone adapter that features 1 analog telephone FXS port and 1 PSTN line FXO port.
Key features
Supports 2 SIP profiles through 1 FXS port and 1 FXO port
Dual 100Mbps LAN and WAN ports
Lifeline support (FXS port will be hard-relayed to FXO port) in case of power outage
3-way voice conferencing per port
Automated & secure provisioning options using TR069
Supports T.38 Fax for reliable Fax-over-IP
Failover SIP server automatically switches to secondary server if main server loses connection
Strong AES encryption with security certificate per unit
Specifications
| Specification | Value |
|---|---|
| SPECS | |
| LINES | 2 lines |
| AUDIO CONFERENCING | 3-Way Voice Conferencing Per Port |
| TELEPHONE INTERFACES | One (1) RJ11 FXS port, One (1) RJ11 FXO PSTN line port with lifeline support |
| NETWORK INTERFACES | Two (2) 10/100Mbps ports (RJ45) with integrated NAT router |
| LED INDICATORS | POWER, LAN, WAN, FXS, FXO |
| TELEPHONY FEATURES | Caller ID display or block, call waiting, flash, blind or attended transfer, forward, hold, do not disturb, 3-way conference |
| FAX OVER IP | T.38 compliant Group 3 Fax Relay up to 14.4kpbs and auto-switch to G.711 for Fax Pass-through |
