GWN7816(P)
The GWN7816(P) are 48-port Layer 3 managed network switches that allow enterprises to build scalable, secure, and high-performance business networks that are fully manageable.
- 48Gigabit Ethernet Ports
- 6SFP+ 10Gigabit Ports
- 48PoE Ports (PoE Models Only)
Product details
The GWN7816(P) are 48-port Layer 3 managed network switches that allow enterprises to build scalable, secure, and high-performance business networks that are fully manageable.
Enterprise-Grade Layer 3 Managed Network Switch
Key features
48 Gigabit Ethernet ports and 6 10Gigabit SFP+ ports
Smart power control to support dynamic PoE/PoE+, PoE++ (GWN7816P) power allocation per port for the PoE models
Supports deployment in IPv6 and IPv4 networks
Reliability features including fault detection, device protection, dual boot, dual system file redundancy, link aggregation, storm control, and more
ARP Inspection, IP Source Guard, DoS protection, port security & DHCP snooping
Embedded controller to manage switch, GDMS Networking and GWN Manager, Grandstream’s cloud and on-premise network management platform, GWN Series Router, CLI management
Built-in QoS allows for prioritization of network traffic
Supports stacking for easy management on one interface while creating redundant backup between multiple devices
DoC - GWN7816
DoC - GWN7816P
DoC - 1.25G Fiber Port Module
DoC - 10G Fiber Port Module
DoC - CRPS-920W for GWN7816P
DoC - RPS-70W for GWN7816
Specifications
| Specification | Value |
|---|---|
| Specifications | |
| Network Protocols | IPv4, IPv6, IEEE 802.3, IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3ae, IEEE 802.3az, IEEE 802.3ad, IEEE 802.3x, IEEE 802.3af/at/bt, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x |
| Gigabit Ethernet Ports | 48 |
| SFP+ 10Gigabit Ports | 6 |
| PoE Ports (PoE Models Only) | 48 |
| Total PoE Output (PoE Models Only) | 740 (60W on Ports 1-8 with PoE++, 30W on all Remaining Ports) |
| Total Non-Blocking Throughput | 108Gbps |
| Switching Capability | 216Gbps |
| Forwarding Rate | 160.704Mpps |
| Switching, Routing, and Multicast | Supports stacking for easy management of multiple devices on one interface while creating redundant backup between devices 32K MAC addresses, including static, dynamic, filtering and sticky MAC address 4K VLANs, port-based VLAN, IEEE 802.1Q VLAN tagging, MAC-based VLAN, protocol-based VLAN, QinQ Private VLAN Voice VLAN including auto voice VLAN, tagged OUI and untagged OUI 32 VLAN virtual interface with 9216 MTU 2K ARP/NDP GVRP(pending) 32 link aggregation Spanning tree, 64 instances for STP/RTSP/MSTP/PVST(+)/RPVST(+) ERPS (pending) 12K(IPv4)/4K(IPv6) routes 32(IPv4)/32(IPv6) static routing Policy routing (pending) Dynamic routing, including RIP, RIPng, OSPF, OSPFv3 and BGP Routing Policy VRRP(pending) IGMP Snooping with IGMPv2 and IGMPv3, 256 IGMP Snooping groups MLD Snooping with MLDv1 and MLDv2, 256 MLD Snooping groups MVR |
| Security | User hierarchical management and password protection, HTTPS, SSH, Telnet Identity authentication including 802.1X authentication and MAC authentication AAA authentication including RADIUS, TACACS+ Storm control Port isolation, port security, sticky MAC Filtering MAC address IP/IPv6 source guard, DoS attack prevention, ARP inspection DHCP/DHCPv6 Snooping Loop protection including BPDU protection, root protection and loopback protection Kensington Security Slot (Kensington Lock) support |
